- GST NO. : 22AJXPC2620C1ZR
- View Mobile Number
30 piece (MOQ)
| Business Type | Exporter, Supplier, Retailer, Trader, Distributor |
| Brand Name | WINTECH |
| Material | CARBIDE |
| Finishing | Coated |
| Click to view more | |
Product Details
Color
Metallic
Condition
New
Size
7.94MM IC
Type
EXTERNAL TURNING
SHAPE
SQUARE
WORKPIECE Material
P/M/K
Product Code
23242105
Delivery Time
5 DAYS
Packaging Details
### Packing Details
* **Packing Type:** Original manufacturer plastic box
* **Quantity per Box:** 10 inserts (may vary depending on product model)
* **Inner Packing:** Individual precision slots to protect cutting edges from damage during storage and transportation
* **Outer Packing:** Durable corrugated carton with protective cushioning for secure shipping
* **Packaging:** Genuine factory-sealed manufacturer packaging
* **Condition:** Brand New
* **Packing Type:** Original manufacturer plastic box
* **Quantity per Box:** 10 inserts (may vary depending on product model)
* **Inner Packing:** Individual precision slots to protect cutting edges from damage during storage and transportation
* **Outer Packing:** Durable corrugated carton with protective cushioning for secure shipping
* **Packaging:** Genuine factory-sealed manufacturer packaging
* **Condition:** Brand New
The SPMG07T308 is a high-performance square carbide indexable drill insert designed for U-drills and indexable drilling systems. It delivers excellent hole accuracy, efficient chip evacuation, and long tool life in medium to high-speed drilling operations. The insert is suitable for CNC machining centers and conventional drilling machines, providing reliable performance on steel, stainless steel, cast iron, and alloy steels.
Technical Specifications
| Product Type | Indexable Drill Insert |
| Model | SPMG07T308 |
| Material | Cemented Carbide |
| Shape | Square |
| Insert Type | Positive |
| Application | U-Drill / Indexable Drilling |
| Inscribed Circle (IC) | 7.94 mm |
| Thickness (S) | 3.97 mm |
| Corner Radius (RE) | 0.8 mm |
| Hole Diameter (d1) | 2.85 mm |
| Point Angle | 11° |
| Cutting Edges | 4 |
| Mounting Style | Mechanical Clamping |
| Weight (1 Piece) | Approx. 3.5 g |
| Color | Grade Dependent |
| Pack Size | Usually 10 Pieces |
The standard SPMG07T308 dimensions are IC 7.94 mm, thickness 3.97 mm, corner radius 0.8 mm, and hole diameter 2.85 mm. Typical insert weight is approximately 3.5 g.
Features
- Premium cemented carbide construction
- High wear resistance
- Excellent toughness
- Four usable cutting edges
- High drilling accuracy
- Efficient chip evacuation
- Low cutting forces
- Long tool life
- Suitable for high-speed machining
- Compatible with indexable U-drills
- Suitable for dry and coolant-assisted machining
Applications
- CNC Drilling
- U-Drill Operations
- Indexable Drilling
- General Hole Making
- High-Speed Drilling
- Production Machining
Suitable Materials
- Carbon Steel
- Alloy Steel
- Stainless Steel
- Cast Iron
- Heat-Resistant Alloys
Advantages
- High hole accuracy
- Stable drilling performance
- Reduced machining time
- Extended insert life
- Lower tooling costs
- Excellent chip control
- Increased productivity
- Reliable performance in industrial machining
Corrosion Resistance
- Good corrosion resistance during storage
- Excellent wear resistance
- Suitable for dry and wet machining
- Grade-dependent coatings provide improved oxidation and corrosion resistance
